Stainless Steel Welding Core Wire

Core Wires

Venus also produces Stainless Steel Core Wires for electrodes manufacturing. We supply to numerous electrode manufacturers around the globe. Our core wires are produced in various grades and in cut lengths or in coil form as per our customer’s needs. We also customize the lengths, packing and packaging as per the need.

We have also developed specialized chemistries for core wires to enhance electrode producers flux requirements and weldability for end customer.

Our Core Wires are manufactured in grades 307Si, 308L, 308LSi, 309, 309L, 309LSi, 309LMo, 310, 312, 316, 316L, 316LSi, 317L, 318Si, 321, 347, 347Si, 409, 409Cb, 409Ti, 410, 410NiMo, 420, 430, 430LNb, 904 L& 2209.

Core Wires
Stainless Steel Core Wires for electrodes manufacturing

Alloys

AWS 304L Mod. 307Si 308L 309L 310 312 316L 347 410NiMo
W. Nr.(EN) 1.4307 1.4370 1.4316 1.4332 1.4842 1.4337 1.4430 1.4551 (13 4)
AWS 308L 309L 316L 430 2209 2594
W. Nr.(EN) 1.4316 1.4332 1.4430 1.4016 (22 9 3 N L) (25 9 4 N L)

We also offer customized chemistry.

Standard Diameter

MM 1.60 2.00 2.40 3.20 4.00 5.00
INCH 0.062 0.080 0.093 0.125 0.157 0.1875

Standard Length

MM 250 300 350 400 450

Customized diameter and length availabel on request.

Packaging

Core Wires
Cut Length

In wooden boxes of
500 – 1000 kg/1000 – 2000 lbs

Coils 300 – 1000 kg/650 – 2200 lbs woundon tabular carrier
Coils

300 – 1000 kg/650 – 2200
lbs woundon tabular carrier

Coils 100 – 200 kg/200 – 500 lbsHDPE wrapped
Coils

100 – 200 kg/200 – 500
lbsHDPE wrapped

We also offer “Customized Packaging & Labelling Solutions” as per requirements.
